- Spec table
| MECH FAN | MECH FAN |
| FAN DIM. | 82.8*81.3*11.5mm |
| START/RATED VOLTAGE | 7V/12V |
| RATED CURRENT | 0.33(0.6MAX.)A |
| POWER | 3.96(7.2MAX.)W |
| RPM | 4200RPM |
| NOISE | 54(57MAX.)dB |
| CONNECT PIN/PITCH | 4P/ |
| Excerpt of suitable series | CreatorPro M16 B13VJ(MS-1585) CreatorPro M16 B13VK(MS-1585) Crosshair 15 C12VE(MS-1585) Crosshair 15 C12VF(MS-1585) Crosshair 15 C12VG(MS-1585) Crosshair 16 A13VGK(MS-1585) Crosshair 17 C12VE(MS-17L5) Crosshair 17 C12VF(MS-17L5) Crosshair 17 C12VG(MS-17L5) Pulse 15 B13VFK(MS-1585) Pulse 15 B13VGK(MS-1585) Pulse 17 B13VFK(MS-17L5) Pulse 17 B13VGK(MS-17L5) |
